Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel
  • Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel
  • Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel
  • Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel

Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel

Place of Origin Jiangsu,China
Brand Name OUCO
Certification ISO/CE/CCS/BV/ABS
Model Number OUCO-GB-4
Product Details
Color:
Customized
Original:
Jiangsu,China
Type:
Clamshell
Power:
Battery
Operation Method:
Wireless Remote Control
Name:
Remote Control Grab
Material:
Q355
Warranty:
12 Months
Highlight:

Clamshell Grab Vessel

,

50 CBM Grab Vessel

,

Clamshell Radio Remote Control Grab

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Shipping Container/Wood Crate/nude
Delivery Time
45 days
Supply Ability
100 sets per year
Product Description

Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel





Work theory

The remote control grab controls the opening and closing of the remote grab by opening and closing the main cylinder solenoid valve. When the slip block slides down to the lower bolster, the slip block is integrated with the lower bolster, and the grab can grab the cargo. When it is necessary to open the grab, press the remote control transmitter to control the solenoid valve to be energized, the hydraulic system oil circuit is opened, the slip block is separated from the lower bearing beam, and the grab is opened to release the cargo. At the same time, the sliding block moves up and collides with the upper bolster. After a delay, the solenoid valve is closed to prepare for the next operation.



Closing Cycle:

When the grab is opening, the moving board is connecting with top roof beam,and separate with down roof beam, at the that time, the hydraulic circuit system is opening, and the piston of hydraulic vat was pulled out by moving board, when grab the goods, the hook of the crane go down, the moving board go down along the hydraulic vat with the piston of the cylinder, when the moving board touch the stroke switch on the down roof beam, the stroke switch stop the eleclromagnetism valve to stop the hydraulic oil . The hook of the crane goes up with moving board and down roof beam, to make the grab close.

Opening Cycle:

Press the radio switch, send the message to the receiver, then the electromagnetism valve open the hydraulic circuit system, the hydraulic vat was extended because of the gravity of goods and down roof beam, the down roof beam was separated from moving board, to make the grab open , and the grab can do the next closing cycle.



Each grab include below parts



Hydraulic seal 1 set
Solenoid valve 1 set
Oil pipe 1 set
Remote control and receiver (including battery, receiver) 1 set
Battery 1 set
Battery charge 1 set
Steel rope model 8X26SW+FC-36strength1770N/mm2) set 1 unit
Gresase nipple 20 units



Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel 0



Product Feature

1.Designed to single wired cranes.

2.No need any electric supply or motor, runs with battery.

3.Opens by radio remote control, closes by rope equipment.

4.When a cylinder fails, it can work single cylinder for a while.

5.Manufactured in range of 1 CBM to 50 CBM capacity.



Transportation

Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel 1



Related products

Hydraulic 50 CBM Max Clamshell Wireless Grab Vessel 2



Our Company



With years of experience, the OUCO Marine Group has its own designing team and manufacturing

factory, excellent European management who has 47 years of experience on offshore business, which

also provides after sales services overseas.

Our production line covers marine and offshore knuckle boom crane, telescopic crane, stiff boom crane,

non-standard steel structure, more environmental-friendly operations and also truck crane with the range

from 15t to 150t.Port industry which includes cranes, hoppers and grabs.

OUCO Machinery can build any type of handling equipment, according to our own design, but also according to provided designs.

We build products according to any certification requested by the client and are able to build them for working in, and under extreme heavy circumstances for working tempertures of - 40C accordingly.



FAQ

We need to know the data as following for designing a accurate plan:
1. What's the lifting material?
2. What's the cubage of the Crane Grab?
3. What's the maximum lifting weight of the crane?
4. What's the working environment?
